AutoTiss 10C Automatic Tissue Microarrayer
SKU: AutoTiss 10C
AutoTiss 10C is a compact, computer-controlled tissue microarrayer designed to automate the transfer of tissue cores from donor blocks into recipient blocks. The system accommodates up to 10 blocks at once and supports five coaxial punch sizes from 0.6 to 2.5 mm. Its integrated software supports Excel-based sample and recipient-block data, allowing workflows to be tracked, saved, repeated, and modified. A graphical interface, automated punch-area selection, CCD imaging, block-height sensing, and a rotary loading tray help streamline routine TMA preparation. The instrument also includes a built-in heating function and optional barcode identification for workflow management.
Specifications
- Capacity: 10 blocks total (9 donor + 1 recipient)
- Punch sizes: 0.6, 1.0, 1.5, 2.0, 2.5 mm coaxial stainless needle sets
- Weight: 45 kg
- Dimensions: W480 × D480 × H470 mm
- Operating temperature: 15–32 °C ambient
- Operating humidity: 20–80%
- Transfer speed: 150 cores/hour
- Power input: 110 V
- Actuator: Electromechanical
- Resolution: 0.1 mm/axis
- Repeatability: ±0.01 mm/axis (hardware section)
- ±0.1 mm/axis (specification section)
- Motor: Micro Step Servo Motor
- Max. loading: XY 8 kg / Z 3 kg
- Max. speed: XY-300-Z-100 mm/sec
- Loading: Rotary/rotation tray with universal/easy loading
- Control: PC-based CNC
- Windows 7, 8, 10 listed
- Camera: 13 MP high-resolution camera with autofocus or scanned image input
- Block detection/height: Auto height detection
- high-precision laser height sensor
- Lighting: LED ring light
- Heating: Built-in heater/block platen heater
- Identification: Optional barcode reader
$108,500.00Price
